Tomei EXPREME Ti TITANIUM MUFFLER for 86/BRZ/FR-S TYPE-80

Tomei EXPREME Ti TITANIUM MUFFLER for 86/BRZ/FR-S TYPE-80

SKU: 440021
£1,305.99
£1,305.99
Sale Sold out
Taxes included. Shipping calculated at checkout.

Some items may take 3-5 days to ship.
Dramatic Weight Reduction & Performance Gains Throughout The Entire Powerband For The 86/BRZ/FRS.

Our high-quality, high-performance muffler that was specifically created for the performance minded end user.
We had developed our own special material to achieve the quality and performance needed. In terms of functionality, the internal structure of the silencer and the layout were designed as straight as possible. With 3 muffler designs available, to suit various tuning needs. To cover all 86/BRZ/FRS tuning trends. This is the clear distinguishing factor of our EXPREME Ti series mufflers.

PRODUCT INFO

APPLICATION TYPE P/N NOTES
86
BRZ
FRS		 TYPE-60R 440020 ※FOR OFF ROAD USE ONLY.
TYPE-60S 440019
TYPE-80 440021

FEATURE / SPEC

KIT CONTENTS




TYPE-60S TYPE-60R TYPE-80
  • MAIN PIPE A (1)
  • MAIN PIPE B (1)
  • MAIN SILENCER(1)
  • TAIL PIPE (1)
  • CLAMP BAND (3)
  • SPRING (4)
  • SOUND REDUCER (1)
  • FLANGE NUT M8 (1)
  • FLANGE BOLT M8 (1)
  • BUTTON BOLT (1)
  • SILENCER BAND (1)
  • SILENCER BAND RUBBER (1)
  • ALLEN KEY (1)
    		•
  • MAIN PIPE A (1)
  • MAIN PIPE B (1)
  • (1)
  • CLAMP BAND (2)
  • SPRING (4)
  • SOUND REDUCER (1)
  • BUTTON BOLT (1)
  • ALLEN KEY (1)
    		•
  • MAIN PIPE A (1)
  • MAIN PIPE B (1)
  • MAIN SILENCER (1)
  • CLAMP BAND (2)
  • SPRING (4)
  • SOUND REDUCER (1)
  • FLANGE NUT M8 (3)
  • FLANGE BOLT M8 L=35 (2)
  • FLANGE BOLT M8 L=25 (1)
  • GASKET (1)
  • BUTTON BOLT (1)
  • SILENCER BAND (1)
  • SILENCER BAND RUBBER (1)
  • ALLEN KEY (1)
    		•
    SPEC
    Our design gives top priority to weight reduction and exhaust flow efficiency. Not too thick and not too thin. To maximize performance gains without sacrificing torque.
    TYPE-60S TYPE-60R TYPE-80 STD
    MATERIAL TITANIUM TITANIUM TITANIUM –
    MAIN PIPE DIAMETER Φ60.5 Φ60.5 Φ80.0 Φ54.0
    MAIN PIPE THICKNESS 1mm 1mm 1mm 1.2ｍｍ
    SILENCER DIAMETER CENTER Φ115
    REAR Φ115    		 Φ115 CENTER Φ115
    REAR Φ152    		 CENTER Φ100
    REAR 350x 190 OVAL
    SILENCER THICKNESS 1mm 1mm 1mm 1.2mm
    EXIT DIAMETER Φ105 Φ105 Φ115 Φ90/75×2
    EXIT THICKNESS 1mm 1mm 1mm 1.2mm
    FLANGE THICKNESS 2.0mm 2.0mm 8.0mm
    (Flat Flange)     		2.0mm
    EXHAUST TEST LEVELS Without Inner Silencer:95db
    With Inner Silencer:92db    		 Without Inner Silencer:102db
    With Inner Silencer:98db    		 Without Inner Silencer:104db
    With Inner Silencer:97db
    WEIGHT 6.4kg 4.6kg 7.3kg 17.4kg
    11.0kg DROP! 12.8kg DROP! 10.1kg DROP!
    DATA
    LAYOUT
    TOMEI ※TYPE=60R MODEL  When aiming for true performance efficiency, we had chosen to design the exhaust with the least amount of bends as possible. Just like the true purpose built race cars, in a racing layout design, yet to still comply with the stock body design so it can be fitted to any street used vehicles.

    A : TAIL PIPE

    Compared with the stock design, our design is single piping all the way for max weight reduction. We have also focused on the design of the muffler to produce the best exhaust sound without compromising performance.

    B : MAIN PIPE

    The pipe diameter was chosen for optimum exhaust flow efficiency. For performance use in mind and weigh reduction. Thus the slide joints was made instead of using the conventional flange and gasket design.

    SECTION PIPE ASSEMBLY

    The conventional style flange is not used to help reduce weight even further. The use of the springs and clamps eliminates the need for gaskets as well.

    STYLE

  • 【TYPE-60S】　The sports model designed for sound quality, noise levels & performance.



  • 【TYPE-60R】　The race model, designed for exhaust flow & weight reduction.



  • 【TYPE-80】　The high flow model for forced induction setups.
