TOMEI

Tomei EXPREME Ti TITANIUM MUFFLER for EVO7-9 4G63 JAPANESE BUMPER

Tomei EXPREME Ti TITANIUM MUFFLER for EVO7-9 4G63 JAPANESE BUMPER

SKU: 440003
£1,305.99
£1,305.99
Sale Sold out
Taxes included. Shipping calculated at checkout.

Some items may take 3-5 days to ship.

High quality production, for true competition use without compromise. Only the best Titanium grade materials are used. From the special racing layout design, made as straight as possible, to the high flow silencer. We have poured our knowledge into it all. When you see our EXPREME Ti system, you can then understand that ours is unrivaled.

PRODUCT INFO

APPLICATION P/N NOTES
Evo.7/8/9 440003 ※ for JAPANESE BUMPER
※FOR OFF ROAD USE ONLY.

FEATURE / SPEC

KIT CONTENTS

  • MAIN PIPE A
  • MAIN PIPE B
  • SILENCER ASSY
  • GASKET
  • WASHER M12
  • NUT M12
  • A/F BOSS PLUG
  • COPPER WASHER
  • CLAMP BAND
  • SPRING
  • SILENCER BAND
  • BAND RUBBER
  • BOLT M8
  • NUT M8 L=25mm
  • SOUND REDUCER
  • BUTTON BOLT
  • ALLEN KEY
  • MUFFLER HANGERS
  • SPACER
  • SPRING WASHER
  • NUT M8 L=60mm
    		•
    SPEC
    TOMEI STD
    MATERIAL TITANIUM IRON
    MAIN PIPE DIAMETER Φ80.0 Φ60.5
    MAIN PIPE THICKNESS 1mm 1.5ｍｍ
    SILENCER DIAMETER Φ152 100×440mm(Oval)
    SILENCER THICKNESS 1mm –
    EXIT DIAMETER Φ115 Φ100
    EXIT THICKNESS 1mm –
    FLANGE THICKNESS 6.0mm 12.0mm
    WEIGHT 4.85kg 16.00kg
    11.15kg DROP!
    DATA
    LAYOUT

    RACING LAYOUT

    For the best exhaust efficiency results minimal bends and curves was the design focus points on this product which aided with the supreme results.

    3 SECTION PIPE ASSEMBLY

    No flanges were fitted for increased weight savings and for a better finish with the race look secure springs and clamp methods.

    COMPATIBLE WITH ALL CT9A EVO MODELS ※JAPANESE BUMPER

    STYLE

  • Evo8




  • Evo9
